Temperature Is Our Business

Japanese site

Heaters...

OMC’s extensive range of electric heating systems is constructed using the company’s own manufactured mineral insulated cables. This manufacturing process oﬀers ease of installation, since the sheath can be supplied to a bend radius of 2.5 times the heater OD. This means the heater can be formed into any desired shape and is high pressure sealed for welding when required into process ﬂanges.

As with OMC’s temperature assemblies, full product certiﬁcation for use in hazardous area applications can be provided, Exde IIC T6 for Zone 1&2 terminated into suitable enclosures.

Aeroheat

AEROHEAT is a long-life mineral insulated metal sheathed heater, developed and based on our superior manufacturing technology of MI cables. Manufactured from a single diameter cable with no external joins to eliminate mechanical failure points, the heater assemblies have an integrated unheated cold section so there is no requirement for additional and costly infrastructure such as water cooling pipe work and systems to maintain lower temperatures required by sealing ﬂange O rings and other sealing port connections.

High Temp Plate Heaters

Okazaki’s high temperature plate heater provides superior performance and uniform surface temperature for semi-conductor manufacturers. Fully manufactured and assembled in our facilities integrating our mineral insulated heaters and thermocouples enables us to control product quality. Each unit is supplied fully tested to ensure surface uniformity within 1% and can be operated to temperatures up to 1000°C.

Micropak

Okazaki’s MICROPAK mineral insulated heaters are ultra-small diameter heaters which oﬀer greater ﬂexibility in the application’s installation. With a small bend radius as a ratio to the outside diameter of the heater, these units can be coiled and freely formed into complex and desired shapes, oﬀering ﬂexibility when space is paramount.

Mineral Insulated Trace Heaters

OMC supplies MI heating cables that provide reliable and rugged heat tracing for demanding applications within the oil & gas process sector. The construction enables the heating of equipment to higher temperatures when required. Various sheath and conductor combinations are available to meet application-speciﬁc requirements.

Process Heaters

OMC’s range of process ﬂanged heaters can be supplied with various process ﬂanged connections and combinations of material to meet the speciﬁc requirements. Outputs range from several dozen W to many thousands of KW. Process welding is carried out to ASME IX and full material certiﬁcation is provided. If required, OMC can also provide the process chamber to suit the heater supplied.

Combustor Heaters

OMC designs and manufactures a range of combustors that comply with all the major international standards. Systems have been supplied to customers that comply with the Construction Code for Pressure Vessels, High Pressure Gas Safety Law, and the Construction Code for Boilers.
